ESCALATE THE GAME

SPESIFIKASI

MESIN

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Tipe	1.5 L SOHC silinder segaris, 16 katup i-VTEC + DBW	1.5 L SOHC silinder segaris, 16 katup i-VTEC + DBW	1.5 L SOHC silinder segaris, 16 katup i-VTEC + DBW	1.5 L SOHC silinder segaris, 16 katup i-VTEC + DBW	1.5 L SOHC silinder segaris, 16 katup i-VTEC + DBW
Sistem Suplai Bahan Bakar	PGM-FI	PGM-FI	PGM-FI	PGM-FI	PGM-FI
Diameter x Langkah	73,0 mm x 89,4 mm	73,0 mm x 89,4 mm	73,0 mm x 89,4 mm	73,0 mm x 89,4 mm	73,0 mm x 89,4 mm
Isi Silinder	1497	1497	1497	1497	1497
Perbandingan Kompresi	10,3 : 1	10,3 : 1	10,3 : 1	10,3 : 1	10,3 : 1
Daya Maksimum	88 Kw (120 PS) / 6.600 rpm	88 Kw (120 PS) / 6.600 rpm	88 Kw (120 PS) / 6.600 rpm	88 Kw (120 PS) / 6.600 rpm	88 Kw (120 PS) / 6.600 rpm
Momen Puntir Maksimum	14,8 kg.m (145Nm) /4.600 rpm	14,8 kg.m (145Nm) /4.600 rpm	14,8 kg.m (145Nm) /4.600 rpm	14,8 kg.m (145Nm) /4.600 rpm	14,8 kg.m (145Nm) /4.600 rpm

DIMENSI/UKURAN

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
PanjangxLebarxTinggi	4.442mm x 1.694mm x 1.477mm	4.442mm x 1.694mm x 1.477mm	4.442mm x 1.694mm x 1.477mm	4.442mm x 1.694mm x 1.477mm	4.442mm x 1.694mm x 1.477mm
Jarak Sumbu Roda	2.600	2.600	2.600	2.600	2.600
Jarak Pijak Depan/Belakang	1.492mm / 1.481mm	1.492mm / 1.481mm	1.476mm / 1.465mm	1.476mm / 1.466mm	1.476mm / 1.466mm
Kapasitas Tangki	40	40	40	40	40

TRANSMISI

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Tipe	5 Speed	CVT	5 Speed	CVT	CVT
1	3,461	2,256 ~ 0,408	3,461	2,256 ~ 0,408	2,256 ~ 0,408
2	1,869	2,256 ~ 0,408	1,869	2,256 ~ 0,408	2,256 ~ 0,408
3	1,235	2,256 ~ 0,408	1,235	2,256 ~ 0,408	2,256 ~ 0,408
4	0,948	2,256 ~ 0,408	0,948	2,256 ~ 0,408	2,256 ~ 0,408
5	0,809	2,256 ~ 0,408	0,809	2,256 ~ 0,408	2,256 ~ 0,408
Reverse	3,307	2,706	3,307	2,706	2,706
Final Gear	4,625	5,436	4,625	5,436	5,436

SISTEM KEMUDI

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Sistem	Rack & Pinion with Electric Power Steering (EPS)	Rack & Pinion with Electric Power Steering (EPS)	Rack & Pinion with Electric Power Steering (EPS)	Rack & Pinion with Electric Power Steering (EPS)	Rack & Pinion with Electric Power Steering (EPS)
Tilt Steering	✔	✔	✔	✔	✔
Telescopic Steering	✔	✔	✔	✔	✔

SISTEM SUSPENSI

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Suspensi Depan	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut	MacPherson Strut
Suspensi Belakang	H-Shape Torsion Beam	H-Shape Torsion Beam	H-Shape Torsion Beam	H-Shape Torsion Beam	H-Shape Torsion Beam

SISTEM REM

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Brake Override System	✔	✔	✔	✔	✔
ABS + EBD	✔	✔	✔	✔	✔
Brake Assist (BA)	✔	✔	✔	✔	✔
Rem Depan	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc	Ventilated Disc
Rem Belakang	Drum	Drum	Drum	Drum	Drum

BAN

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Ban	175 / 65 R15	175 / 65 R15	185 / 65 R16	185 / 65 R16	185 / 65 R15
Roda	Alloy Wheel 15″ x 5 1/2J	Trim Wheel 15″ x 5 1/2 J	Trim Wheel 16″ x 6 J	Trim Wheel 16″ x 6 J	Trim Wheel 16″ x 6 J

EKSTERIOR

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Front Lamp	Halogen Headlight	Halogen Headlight	Halogen Headlight	Halogen Headlight	Halogen Headlight
Fog Lamp	✔	✔	✔	✔	✔
Front Grille	Silver	Silver	Chrome Front Grille	Chrome Front Grille	Platinum
Door Mirror	Body Color (with LED Turning Signal)	Body Color (Power Retractable w/ LED Turning Signal)	Body Color (Power Retractable w/ LED Turning Signal)	Body Color (Power Retractable w/ LED Turning Signal)	Body Color (Power Retractable w/ LED Turning Signal)
Door Handle	Body Color	Body Color	Chrome	Body Color	Chrome
Led High Mount Stop Lamp	✔	✔	✔	✔	✔
Shark Fin Antenna	✔	✔	✔	✔	✔

INTERIOR

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Audio	Double DIN AM/FM Single Disc MP3/WMA, CD Player + USB Port + AUX Input + Made for iPhone +Illumination Display	Double DIN AM/FM Single Disc MP3/WMA, CD Player + USB Port + AUX Input + Made for iPhone	6,1″ Touch Screen Display, AM/FM Radio, Single Disc MP3/WMA, CD/DVD Player + USB Port + AUX Input Connect wit iPhone App Mode (need additional cable and only for iPhone 4 and 4s)	6,1″ Touch Screen Display, AM/FM Radio, Single Disc MP3/WMA, CD/DVD Player + USB Port + AUX Input Connect wit iPhone App Mode (need additional cable and only for iPhone 4 and 4s)	6,1″ Touch Screen Display, AM/FM Radio, Single Disc MP3/WMA, CD/DVD Player + USB Port + AUX Input Connect wit iPhone App Mode (need additional cable and only for iPhone 4 and 4s)
Multi Information LCD Display (MIL)	✔	✔	✔	✔	✔
ECO Assist	✔	✔	✔	✔	✔
One Push Ignition System			✔	✔	✔
Leather Steering & Shift Knob					✔
Audio Steering Switch			✔	✔	✔
Paddle Shift		✔		✔	✔
Cruise Control			✔	✔	✔
Auto Door Lock by Speed	✔	✔	✔	✔	✔
Power Window	✔	✔	✔	✔	✔
Tweeter			✔	✔	✔
Trunk Capacity (liter)	485	485	485	485	485
Green Glass	✔	✔	✔	✔	✔
Rear Ventilation AC			✔	✔	✔
Rear Seat Fold Down			✔	✔	✔
Auto A/C with Smart Touch			✔	✔	✔
Power Outlet	✔	✔	✔	✔	✔
Rear Armrest with Cup Holder			✔	✔	✔
Seat Back Pocket	✔	✔	✔	✔	✔
Cup Holder	6	6	8	8	8

FITUR KESELAMATAN

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Struktur Rangka Bodi	G-CON + ACE	G-CON + ACE	G-CON + ACE	G-CON + ACE	G-CON + ACE
Side Airbags					✔
Side Curtain Airbags					✔
Pedestrian Protection	✔	✔	✔	✔	✔
Dual Front SRS Airbags	✔	✔	✔	✔	✔
Sabuk Keselamatan (Front)	Seatbelt 3P ELR (x2)	Seatbelt 3P ELR (x2)	Seatbelt 3P ELR (x2)	Seatbelt 3P ELR (x2)	Seatbelt 3P ELR (x2)
Sabuk Keselamatan (Rear)	Seatbelt 3P ELR (x2)	Seatbelt 3P ELR (x2)	Seatbelt 3P ELR (x2)	Seatbelt 3P ELR (x2)	Seatbelt 3P ELR (x2) + 2P MAN x1
Pretensioner w/ Load Limiter Seatbelt	✔	✔	✔	✔	✔
ISOFIX & Tether	✔	✔	✔	✔	✔
VSA	✔	✔	✔	✔	✔
Hill Start Assist	✔	✔	✔	✔	✔
Emergency Stop Signal (ESS)	✔	✔	✔	✔	✔

SISTEM KESELAMATAN

	New City S	New City S CVT	New City E	New City E CVT	New City ES CVT
Key Type	Wave Key	Wave Key	Wave Key	Wave Key	Smart Key
Keyless Entry	✔	✔	✔	✔	✔
Immobilizer	✔	✔	✔	✔	✔
Alarm System	✔	✔	✔	✔	✔
Smart Entry	✔		✔	✔	✔
